•600W Maximum (100W x 4 + 200W x 1) •65W RIMS + 100W RIMS per Channel into 4 Ohms at 0.05% THD (20Hz-20KHz) •75W RMS + 150 RIMS into 2 Ohms at 1 % THD •300W RIMS Bridged (150W RIMS x 2 - 4-Channel Section) into 4 Ohms at 1 % THD•Mosfet Power Supply • 2 Ohm Stable •Signal to Noise Ratio >90dB •High/Low Level Inputs 4-Channel Section, Low Level Inputs Mono Section •2/3/4 Channel Operations with Mode Switch 4-Channel Section •Variable High/Low Pass Crossovers 4-Channel Section •Variable Low Pass Crossover Mono Section •45Hz 12 dB Bass Boost Mono Section •5th and 6th Phantom Channels for Powering Center Speaker and Subwoofer 4Channel Section •Circuit/Thermal Overload Protection •Gold Plated Terminals .Chassis Mounted Fuses •W9.25" x H2.25" x D19.5"
|
|
